MAGBORE
LIGHTWEIGHT, COMPACT, PORTABLE MAGNETIC DRILL STAND
The easy-to-use Kanetec Magbore Drill Stand offers sure, positive, firm footing for your precision drill jobs. It has the portability of a hand held drill,with the accuracy and stability of a drill press. The Magbore weighs less than 13 pounds without drill, 19 pounds with drill. It gives you a portable machine shop for in-house or on-site projects. It is easy to maneuver and position into areas of restricted accessibility, and once it is set, it will magnetically hold to the most precise drilling position even on plates as thin as 1/5 inch.
KCD-MN1-MWK1a is made to hold Milwaukee Drill Model 0299-20.
No other drill model will fit this stand.
The clamping bracket is designed for use with the Milwaukee Electric Magnum Hole Shooter model 0299-20. Milwaukee has discontinued this model, we are currently revising the bracket for compatibility with Dewalt models # DW235G and DWD210G. The new brackets should be available mid 2026.
Replacement parts for the KCD-MN1-MWK1 and KCD-MN1-MWK1A are available for purchase here:
https://kanetecusacorp.godaddysites.com/ols/categories/magbore-replacement-parts
Power Requirements (single phase) AC110-120V
Magnet Dimensions: 4” dia x 2 3/8” h (104mm x 60mm)
Overall Width (without drill) 9” (229mm)
Height 9.5” Lowered 11.75” Extended
Holding Power of Magnet: 770 LBF measured on 1” thick mild steel
Maximum Stroke: 3.9” (10mm)
$1,080.00
Order Here:
KCD-MN1-MWK1A
Parts Lists:
